Projection Room

Enter Hollywood

Delivering a blockbuster experience

Whatever the size and format of your venue, Sharp/NEC has a customisable projection solution to suit. Laser light source technology is reinventing the dynamics of the movie theatre with new levels of image brightness, power usage, reliability and service free operation. Traditional lamp based projection is also available should the application demand it.

Laser Phosphor based projectors are the ideal choice for small and midsized screens whereas RB Laser based projectors combine the advantages of a wide colour space and bright image output for mid and larger sized screens. RGB Laser based projectors incorporate the future colour space REC2020 delivering a wider range of rich and natural colours supporting Premium Large Format (PLF) and special format screens.

This is one of the best picture qualities I have ever seen on a cinema projector
Franz Kober, CEO of Cine Project

Choosing the Optimum DC Solution

Model	Supported Screen Size	Light Source	Suitable For
NEC NC1000C	up to 10.6 meters (34 feet)	NSH Lamp	Small screens, small projection booths, mobile cinemas
NEC NC1202L	up to 12 meters (39 feet)	Laser Phosphor	Small to medium screens or small projection booths
NEC NC1402L	up to 14 meters (46 feet)	Laser Phosphor	Small to medium screens or small projection booths
NEC NC1503L	up to 17 meters (56 feet)	Laser RB	Small to medium screens or small projection booths
NEC NC1803ML	up to 19 meters (62 feet)	Laser Phosphor	Medium sized screens
NEC NC1843ML	up to 19 meters (62 feet)	Laser Phosphor	Medium sized screens
NEC NC2003ML	up to 22 meters (72 feet)	Laser RB	Medium sized screens
NEC NC2041L	up to 20 meters (65 feet)	Laser RB	Medium sized screens
NEC NC2043ML	up to 20 meters (65 feet)	Laser RB	Medium sized screens
NEC NC2403ML	up to 22 meters (72 feet)	Laser RB	Medium sized screens
NEC NC2443ML	up to 22 meters (72 feet)	Laser RB	Medium sized screens
NEC NC3540LS	up to 28 meters (91 feet)	RGB Laser	Large cinemas that require premium image quality
NEC NC3541L	up to 32 meters (104 feet)	Laser RB	Large cinemas that require premium image quality
NEC NC603L	up to 11 meters (36 feet)	Laser Phosphor	Small screens and projection booths as well as boothless cinemas

NEC NC1000C

Small yet powerful! Epic cinematic experiences for mobile and smaller cinema screens Designed for theatres with smaller screens or small projection booths, the NC1000C projector delivers an enhanced cinema experience with perfect images. …

Cinema Lamp Projector
Type	DLP
Supported Screen Size	up to 10.6 meters (34 feet)
Resolution	2048 x 1080
Light Source	NSH Lamp

NEC NC1202L

Quietest projection performance for mid-sized screens Built upon the latest Laser light source technology, the NC1202L digital cinema projector impresses audiences with crisp colours and premium quality imaging. At just 48dB in operation, the …

Cinema Laser Projector
Type	DLP
Supported Screen Size	up to 12 meters (39 feet)
Resolution	2048 x 1080
Light Source	Laser Phosphor

NEC NC1402L

Quietest projection performance for mid-sized screens Built upon the latest Laser light source technology, the NC1402L digital cinema projector impresses audiences with crisp colours and premium quality imaging. At just 49dB in operation, the …

Cinema Laser Projector
Type	DLP
Supported Screen Size	up to 14 meters (46 feet)
Resolution	2048 x 1080
Light Source	Laser Phosphor

NEC NC1503L

Quietest projection performance for mid-sized screens With the latest RB Laser light source technology which is almost entirely speckle-free, the NC1503L digital cinema projector can be used with a high gain screen, impressing audiences with …

Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 17 meters (56 feet)
Resolution	2048 x 1080
Light Source	Laser RB

NC1803ML_slant_right_logoLaserPhosphor_web

NEC NC1803ML

Modular Cinema Projection – a new standard in adaptable screening The world’s first cinema projector series offering a modular laser light system with projector head, all in one box. The modular concept allows you to plug-in the appropriate light …

Cinema Laser Projector
Type	DLP
Supported Screen Size	up to 19 meters (62 feet)
Resolution	2048 x 1080
Light Source	Laser Phosphor

NEC_NP-NC1843ML_upperslant_right_web-LaserPhosphorLogo

NEC NC1843ML

Greater flexibility with modular cinema projection solutions Joining Sharp/NEC’s modular cinema projection solutions, the NC1843ML provides high flexibility and future-proof adaption. The modular concept allows for simple upgrade from 2K to 4K …

4K Cinema Laser Projector
Type	DLP
Supported Screen Size	up to 19 meters (62 feet)
Resolution	4096 x 2160
Light Source	Laser Phosphor

NCxx03ML-Series_slant_right_logoRBLaser_web

NEC NC2003ML

Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 22 meters (72 feet)
Resolution	2048 x 1080
Light Source	Laser RB

NC2041L_L2K30ZM_upperslant_web_laserlogo

NEC NC2041L

The all-in-one RB laser projector for medium sized format screensWith the NEC NC2041L 4K RB laser projector cinemas are taking advantage of both laser phosphor and RGB laser technologies resulting in a powerful projector which delivers compelling …

4K Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 20 meters (65 feet)
Resolution	4096 x 2160
Light Source	Laser RB

NEC_NP-NC2443ML_upperslant_right_web-RBLaserLogo

NEC NC2043ML

Greater flexibility with modular cinema projection solutions Joining Sharp/NEC’s modular cinema projection solutions, the NC2043ML provides high flexibility and future-proof adaption. The modular concept allows for simple upgrade from 2K to 4K …

4K Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 20 meters (65 feet)
Resolution	4096 x 2160
Light Source	Laser RB

NEC NC2403ML

Modular Cinema Projection – a new standard in adaptable screening The world’s first cinema projector offering a modular laser light system with projector head, all in one box. The modular concept allows you to plug-in the appropriate light …

Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 22 meters (72 feet)
Resolution	2048 x 1080
Light Source	Laser RB

NEC NC2443ML

Greater flexibility with modular cinema projection solutions Joining Sharp/NEC’s modular cinema projection solutions, the NC2443ML provides high flexibility and future-proof adaption. The modular concept allows for simple upgrade from 2K to 4K …

4K Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 22 meters (72 feet)
Resolution	4096 x 2160
Light Source	Laser RB

NEC NC3540LS

The Blockbuster Cinematic experience reaches a whole new level With the NEC NC3540LS 4K RGB laser projector, cinema is now entering a new era of projection quality. Delivering outstanding resolution and for the first time on any projection …

4K Cinema RGB Laser Projector
Type	DLP
Supported Screen Size	up to 28 meters (91 feet)
Resolution	4096 x 2160
Light Source	RGB Laser

NC3541L_L2K30ZM_upperslant_web_laserlogo

NEC NC3541L

The first RB laser projector for premium and large format screensWith the NEC NC3541L 4K RB laser projector cinemas are taking advantage of both laser phosphor and RGB laser technologies resulting in a powerful projector which delivers compelling …

4K Cinema RB Laser Projector
Type	DLP
Supported Screen Size	up to 32 meters (104 feet)
Resolution	4096 x 2160
Light Source	Laser RB

NEC NC603L

Silent, sealed, sustainable The NC603L digital cinema projector guarantees highest efficiency with the latest generation laser technology. Furthermore, its low noise level of less than 39dB makes it the quietest in its category and perfectly …

Cinema Laser Projector
Type	DLP
Supported Screen Size	up to 11 meters (36 feet)
Resolution	2048 x 1080
Light Source	Laser Phosphor
